1. Overview
AiPi-LRW-TH1 is a LoRaWAN sensor universal board designed by the Ai-Thinker open source team for Ra-08. It includes a universal sensor interface that supports I2C+ADC+GPIO, a battery power supply interface, a battery charging interface and other interfaces. It supports DIP switch turns the power on and off.
AiPi-LRW-TH1 can be used in various scenarios to create smart agriculture, smart street lights, and smart homes. After the sensor data is collected by Ra-08, it is transmitted to the RG-02 gateway through the LoRaWAN protocol and uplinked to the LoRaWAN server. The data transmission distance is up to 4 kilometers. Achieve low-power standby in standby state when no data is sent.
2. Development data
2.1 Instructions
AiPi-LRW-TH1 Factory firmware usage documentation:click to download
2.2 Schematic diagram
AiPi-LRW-TH1 schematic diagram:click to download
2.3 PCBA data
- AiPi-LRW-TH1 PCBA data:click to download
- AiPi-LRW-TH1 hardware engineering open source address:https://oshwhub.com/ai-thiner_openteam/aipi-lrw-th1_v1-0
2.4 Source code and firmware
- AiPi-LRW-TH1 factory firmware:click to download
- AiPi-LRW-TH1 Firmware source code Github address:https://github.com/Ai-Thinker-Open/Ai-Thinker-LoRaWAN-Ra-08/tree/AiPi-LRW
- AiPi-LRW-TH1 Firmware source code Github address:https://gitee.com/Ai-Thinker-Open/Ai-Thinker-LoRaWAN-Ra-08/tree/AiPi-LRW
3. Other information
- Burning tool :click to download
4. Tutorials
- AiPi environment construction
- practical tool:click to download: Tool Usage (Contributor: “业余菜狗”-AiThinker Forum User-http://bbs.ai-thinker.com)
- AiPi Development essence
- Other Tutorial Collections:http://bbs.ai-thinker.com/forum.php?mod=forumdisplay&fid=189
